Büssing Präsident 14 (in Berlin: E2U S)

Fahrzeugtyp:
Stadt-Linienbus
Baujahr Fahrzeug:
1962
Baujahr Modellreihe:
1961-1969
Herkunftsland:
Motoren/Fahrleistungen
Reifen/Räder/Getriebe
Getriebe/Antrieb:
Voith Diwabus 200S Automatik 2 Vorwärts, 1 Rückwärts / 4x2
Abmessungen/Gewichte
Lä.xBr.xHö. // Überhang v/h:
11790 mm x 2500 mm x 3100 mm // 2810/3500 mm
Radstände - Spur v/m/h:
5400 mm - 2095/1800 mm
Einige Berechnungen:
Grundfläche: ca. 29.47 m² - Stirnfläche: ca. 6.39 m² - LxBxH: ca. 91.37 m³
Gewichte leer/zGG/zZGG:
7940 kg / 15415 kg / ? kg
max. Achslasten tech./zul.:
1.: ?/6500 kg  2.: ?/10000 kg
Nutzlast/-verhältnis:
7475 kg / 0.94
Leistungsgew. leer/zGG/zZGG:
52.9 / 102.8 / ? kg/PS // 18.9 / 9.7 / ? PS/Tonne
Wendekreis:
22.4 m
Sitzplätze/Stehplätze:
28/85
Produktionszahlen
217 (alle E2U 62S/63S für West-Berlin)
Geschichte
Ãœber dieses Modell:
Mit der Bezeichnung E2U S wurden für West-Berlin 1962 und 1963 217 Busse gefertigt, sie waren dort im Liniennetz bis 1976 im Einsatz.

Dieser Bus war als Stadt-Linienbus in West-Berlin im Einsatz.
